MIL-C-11015/2D
TABLE I. Style CK22 characteristics.
Rated
Rated temperature
Capacitance
voltage
and voltage-
Capacitance
tolerance
PIN
1/
temperature limits
Volts, dc
pF
CK22AX120K
500
AX
12
K
CK22AX150K
500
AX
15
K
CK22AX180K
500
AX
18
K
CK22AX220K
500
AX
22
K
CK22AX270K
500
AX
27
K
CK22AX330K
500
AX
33
K
CK22AX390K
500
AX
39
K
CK22AX470K
500
AX
47
K
CK22AX560K
500
AX
56
K
CK22AX680-
500
AX
68
K, M
CK22AX820K
500
AX
82
K
CK22AX101-
500
AX
100
K, M
CK22AX121K
500
AX
120
K
CK22AX151-
500
AX
150
K, M
CK22AX181K
500
AX
180
K
CK22AX221-
500
AX
220
K, M
CK22AX271K
500
AX
270
K
CK22AX331-
500
AX
330
K, M
CK22AX391K
500
AX
390
K
CK22AX471-
500
AX
470
K, M
CK22AX561K
500
AX
560
K
CK22AX681-
500
AX
680
K, M
1/ Where applicable, the complete PIN will include an additional symbol to indicate capacitance tolerance.
REQUIREMENTS
Design and construction:
Dimensions and configuration - See figure 1.
Case type - Tubular with radial leads.
Capacitance value - See table I.
Capacitance tolerance -
10 percent (K) or 20 percent (M) as shown in table I.
Rated temperature - -55 C to +85 C.
Dielectric withstanding voltage: In accordance with MIL-C-11015.
Dielectric:
Test voltage - 250 percent of rated voltage.
Body insulation: Shall be able to withstand 1,300 volts for 5 1 seconds between leads and a V-block which
shall extend beyond the ends of the capacitor body.
Barometric pressure (reduced): In accordance with MIL-C-11015 and method 105 of MIL-STD-202, 0.82 inch of
mercury (80,000 ft).
Test potential - 150 percent of rated voltage.
