MIL-C-11015/14D
REQUIREMENTS
Design and construction:
Dimensions and configuration - See figure 1.
Case type - Stand-off.
Capacitance value - See table I.
Capacitance tolerance -
10 percent (K) or 20 percent (M) as shown in table I.
Rated temperature - -55 C to +85 C.
Dielectric withstanding voltage: In accordance with MIL-C-11015.
Dielectric (DWV):
Test voltage - 250 percent of rated voltage, applied between the case and terminal.
Body insulation: Not applicable.
TABLE I. Style CK80 characteristics.
Rated
Rated temperature
Capacitance
voltage
and voltage-
Capacitance
tolerance
PIN
1/
temperature limits
Volts, dc
pF
CK80AX100-
500
AX
10
K, M
CK80AX330-
500
AX
33
K, M
CK80AX470-
500
AX
47
K, M
CK80AX680-
500
AX
68
K, M
CK80AX101-
500
AX
100
K, M
CK80AX471-
500
AX
470
K, M
CK80AX681-
500
AX
680
K, M
CK80AW102M
500
AW
1,000
M
CK80AW152M
500
AW
1,500
M
1/ Where applicable, the complete PIN will include an additional symbol to indicate capacitance tolerance.
Barometric pressure (reduced): In accordance with MIL-C-11015 and method 105 of MIL-STD-202, condition B
(50,000 ft).
Test potential - 150 percent of rated voltage, applied between the case and terminal.
Insulation resistance (IR): In accordance with MIL-C-11015 and method 302 of MIL-STD-202, condition B.
20,000 megohms, minimum.
Dissipation factor (DF): 1.5 percent, maximum (voltage-temperature limit X) or 2.0 percent, maximum (voltage-
temperature limit W).
Vibration, high frequency: In accordance with MIL-C-11015 and method 204 of MIL-STD-202, condition D
(20 g's).
Thermal shock and immersion: In accordance with MIL-C-11015.
IR - 3,000 megohms, minimum.
