MIL-C-11015/13E
REQUIREMENTS
Design and construction:
Dimensions and configuration - See figure 1.
Case type - Feed thru.
Capacitance value - See table I.
Capacitance tolerance -
10 percent (K) or 20 percent (M) as shown in table I.
Rated temperature - -55 C to +85 C, voltage derated linearly to 50 percent at +125 C (see figure 2).
Dielectric withstanding voltage: In accordance with MIL-C-11015.
Dielectric (DWV):
Test voltage: 2,000 volts dc for 1,000 volt capacitors, or 250 percent of rated voltage for 500-volt
capacitors, applied between the case and either terminal.
Body insulation: Not applicable.
TABLE I. Style CK70 characteristics.
Rated
Rated temperature
Capacitance
voltage
and voltage-
Capacitance
tolerance
PIN
1/
temperature limits
volts, dc
pF
CK70AX100-
1,000
AX
10
K, M
CK70AX330-
1,000
AX
33
K, M
CK70AX470-
1,000
AX
47
K, M
CK70AX680-
1,000
AX
68
K, M
CK70AX101-
1,000
AX
100
K, M
CK70AX471-
500
AX
470
K, M
CK70AX681-
500
AX
680
K, M
CK70AW102M
500
AW
1,000
M
CK70AW152M
500
AW
1,500
M
1/ Where applicable, the complete PIN will include an additional symbol to indicate capacitance tolerance.
Barometric pressure (reduced): In accordance with MIL-C-11015 and method 105 of MIL-STD-202, condition B
(50,000 ft).
Test potential: 100 percent of rated voltage for 1,000-volt capacitors, or 150 percent of rated voltage for 500-
volt capacitors, applied between the case and either terminal.
Insulation resistance (IR): In accordance with Mil-C-11015 and method 302 of MIL-STD-202, condition B.
20,000 megohms, minimum, measured between either insulated point and the capacitor case.
Dissipation factor (DF): 1.5 percent, maximum (voltage-temperature limit X) or 2.0 percent, maximum (voltage-
temperature limit W).
Vibration, high frequency: In accordance with MIL-C-11015 and method 204 of MIL-STD-202, condition D
(20 g's).
2
