MIL-C-11015/12F
TABLE I. Style CK63 characteristics.
Capacitance
Capacitance
Rated
Rated temperature
tolerance
voltage
and voltage-
PIN
1/
temperature limits
Volts, dc
pF
CK63CZ681--
500
CZ
680
K, M
CK63CZ821K-
500
CZ
820
K
CK63CZ102--
500
CZ
1,000
K, M
CK63CZ152--
500
CZ
1,500
K, M
CK63CZ222--
500
CZ
2,200
K, M
CK63BX222--
500
BX
2,200
K, M
CK63CZ332--
500
CZ
3,300
K, M
CK63BX332--
500
BX
3,300
K, M
CK63AW472M-
1,000
AW
4,700
M
CK63AY103M-
1,000
AY
10,000
M
CK63AW103M-
500
AW
10,000
M
1/ Where applicable, the complete PIN will include an additional symbol to indicate capacitance tolerance. The
PIN will also include the letter "E" to indicate an epoxy coated capacitor (when applicable) or "-" will be deleted
for wax impregnated case.
REQUIREMENTS
Design and construction:
Dimensions and configuration - See figure 1.
Case type - Disk, wax impregnated or epoxy coated (E).
Capacitance value - See table I.
Capacitance tolerance -
10 percent (K) or 20 percent (M) as shown in table I.
Rated temperature - -55 C to +85 C (A); or -55 to +125 C (B); or -55 C to +150 C (C) as shown in table I.
Dielectric withstanding voltage (DWV): In accordance with MIL-C-11015.
Dielectric:
Test voltage - 250 percent of rated voltage.
Body insulation:
Test potential - 1,300 volts dc.
Barometric pressure (reduced): In accordance with MIL-C-11015 and method 105 of MIL-STD-202; condition B
(50,000 ft) for voltage-temperature limit AY, or 0.82 inch of mercury (80,000 ft) for voltage-temperature limits AW,
BX, and CZ.
Test potential - 150 percent of rated voltage.
Insulation resistance (IR): In accordance with MIL-C-11015 and method 302 of MIL-STD-202, condition B.
200,000 megohms, minimum.
