MIL-C-11015/10G
TABLE I. Style CK61 characteristics.
Rated
Rated temperature
Capacitance
Capacitance
Part or Indentifying
Voltage
and voltage-
(pF)
tolerance
Number (PIN) 1/
(Volts, dc)
temperature limits
CK61CZ2R2--
500
CZ
2.2
K, M
CK61CZ3R3--
500
CZ
3.3
K, M
CK61CZ4R7--
500
CZ
4.7
K, M
CK61CZ6R8--
500
CZ
6.8
K, M
CK61CZ100--
500
CZ
10
K, M
CK61CZ150--
500
CZ
15
K, M
CK61CZ220--
500
CZ
22
K, M
CK61CZ330--
500
CZ
33
K, M
CK61CZ470--
500
CZ
47
K, M
CK61CZ680--
500
CZ
68
K, M
CK61CZ101--
500
CZ
100
K, M
CK61CZ151--
500
CZ
150
K, M
CK61BX221--
500
BX
220
K, M
CK61CZ221--
500
CZ
220
K, M
CK61BX331--
500
BX
330
K, M
CK61CZ331--
500
CZ
330
K, M
CK61BX471--
500
BX
470
K, M
CK61CZ471--
500
CZ
470
K, M
CK61BX681--
500
BX
680
K, M
CK61AW222M-
500
AW
2,200
M
1/ Where applicable, the complete PIN will include an additional symbol to indicate capacitance tolerance. The PIN
will also include the letter "E" to indicate an epoxy coated capacitor (when applicable) or "-" will be deleted for wax
impregnated case.
REQUIREMENTS
Design and construction:
Dimensions and configuration: See figure 1.
Case type: Disk, wax impregnated or epoxy coated (E).
Capacitance value: See table I.
Capacitance tolerance: ±10 percent (K) or ±20 percent (M) as shown in table I.
Rated temperature: -55°C to +85°C (A), or -55°C to +125°C (B), or -55°C to +150°C (C), as shown in table I.
Dielectric withstanding voltage(DWV): In accordance with MIL-C-11015.
Dielectric:
Test voltage: 250 percent of rated voltage.
Body insulation:
Test potential: 1,300 volts dc.
2
